Motor current 4. Page 17 Default Func. For your convenience If looking through the Hitachi L user manual directly on this website is not convenient for you, there are two possible solutions: Full Screen Viewing - to easily view the user manual without downloading it to your hitachi l100you can use full-screen viewing mode. Is that possible and if yes how to do it.
If not, do you know a drive that can do that. The relay contacts normally open N.
The relay contacts switch to the opposite position when it is in Trip Mode or when input power is Off. All hitachi l100 input signals must use the analog ground [L]. A GND If you use either the voltage or current hitachi l100 input, you must select one of them using the logic input terminal function [AT] analog type.
If terminal [AT] is Off, the hitachi l100 input [O] can command the inverter output frequency. Hitachi l100 [AT] terminal function is covered in the logic input section on page 4— The potentiometer uses the 10V reference [H] and the analog ground [L] for excitation, and the voltage input for the 1 to 2 k Ohms, 2 Watts signal. By default, the [AT] terminal selects the voltage input when it is Off. Take care to use the proper resistance for the potentiometer, which is 1 to 2 k Ohms, 2 Watts.
Voltage Input — The voltage input circuit uses terminals hitachi l100 and [O]. Attach the hitachi l100 shield wire only to terminal [L] on the inverter. Maintain the voltage within specifications do not apply negative voltage. The current come from a sourcing type transmitter; a sinking type will not work!
Lenze SCF Series Drives Distributors Valin
This means the current 4 to In some cases, this hitachi l100 only a panel-mounted analog meter moving-coil type. In other cases, a controller device such as a PLC may command the inverter frequency and other functions. Sometimes it is useful to have the inverter transmit the real-time output frequency value back to the controller to confirm actual operation. The hitachi l100 output function serves these purposes.
It uses terminal [L] as analog GND reference. If needed, you can configure terminal [FM] to transmit the inverter current output value hitachi l100.
Parameter C23 selects the output signal data and transmission format. The pulse-width modulated signal is automatically hitachi l100 by the inertia of the moving-coil mechanism. Be sure to use a 10V full-scale DC voltmeter.
|geforce fx5200 ddr 256mb pci||You might also like|
|radeon b276||Best offer|
The signal period T is fixed at hitachi l100 ms, and the amplitude is fixed at 10 VDC. The signal on [FM] reaches full scale when the inverter outputs the maximum frequency.
You can scale the hitachi l100 cycle with a scale factor setting with parameter BFor the best results with the L Series inverter, carefully read this manual and all of location are the responsibility of the user and are not provided by Hitachi. LMFR to LMFR.
